Warenkorb ( )| Datenblatt | Foto | Mfr. Teil # | Lagerbestand | Preis | Menge | Packaging | Series | ProductStatus | Capacitance | Tolerance | Voltage-Rated | ESR(EquivalentSeriesResistance) | Lifetime@Temp | OperatingTemperature | Polarization | Ratings | Applications | RippleCurrent@LowFrequency | RippleCurrent@HighFrequency | Impedance | LeadSpacing | Size/Dimension | Height-Seated(Max) | SurfaceMountLandSize | MountingType |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
|
M39018/04-2164MALUM-SCREW TERMINAL |
2777 | 336.54 |
In den WarenkorbJetzt anfragen |
Bulk | * | Active | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
|
Datenblatt |
|
UWX1C100MCL1GBCAP ALUM 10UF 20% 16V SMD |
3810 | 0.27 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UWX | Not For New Designs | 10 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 23 mA @ 120 Hz | 34.5 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
UUD1C101MCL1GSCAP ALUM 100UF 20% 16V SMD |
2521 | 0.37 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UUD | Active | 100 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 115 mA @ 120 Hz | 230 mA @ 100 kHz | 440 mOhms | - | 0.248 Dia (6.30mm) | 0.228 (5.80mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
EEE-1CA100SRCAP ALUM 10UF 20% 16V SMD |
86190 | 0.39 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | S | Not For New Designs | 10 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 28 mA @ 120 Hz | 47.6 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
UWT1V101MCL1GSCAP ALUM 100UF 20% 35V SMD |
3655 | 0.37 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UWT | Active | 100 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 84 mA @ 120 Hz | 126 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.303 (7.70mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
UWX1C101MCL1GBCAP ALUM 100UF 20% 16V SMD |
180835 | 0.35 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UWX | Not For New Designs | 100 µF | ±20% | 16 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Polar | - | General Purpose | 86 mA @ 120 Hz | 129 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.213 (5.40mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
EMVE160ADA101MF55GCAP ALUM 100UF 20% 16V SMD |
3176 | 0.36 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Alchip™- MVE | Active | 100 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | - | General Purpose | 69 mA @ 120 Hz | - | - | - | 0.248 Dia (6.30mm) | 0.205 (5.20mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
EEE-FC1C100RCAP ALUM 10UF 20% 16V SMD |
449514 | 0.40 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | FC | Not For New Designs | 10 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 45 mA @ 120 Hz | 60 mA @ 100 kHz | 3 Ohms | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
EEE-FC1H2R2RCAP ALUM 2.2UF 20% 50V SMD |
13064 | 0.40 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | FC | Not For New Designs | 2.2 µF | ±20% | 50 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 22.5 mA @ 120 Hz | 30 mA @ 100 kHz | 5 Ohms | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
EEE-1CA470WRCAP ALUM 47UF 20% 16V SMD |
2315 | 0.42 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | S | Not For New Designs | 47 µF | ±20% | 16 V | - | 1000 Hrs @ 85°C | -40°C ~ 85°C | Polar | AEC-Q200 | Automotive | 39 mA @ 120 Hz | 66.3 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
Datenblatt |
|
EEE-FK1E100RCAP ALUM 10UF 20% 25V SMD |
89202 | 0.46 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | FK | Active | 10 µF | ±20% | 25 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 67.5 mA @ 120 Hz | 90 mA @ 100 kHz | 1.35 Ohms | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
EEE-FK1V100URCAP ALUM 10UF 20% 35V SMD |
2049 | 0.46 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | FK | Active | 10 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 67.5 mA @ 120 Hz | 90 mA @ 100 kHz | 1.35 Ohms | - | 0.157 Dia (4.00mm) | 0.240 (6.10mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
EEE-HB1V100RCAP ALUM 10UF 20% 35V SMD |
3298 | 0.46 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | HB | Active | 10 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 28 mA @ 120 Hz | 47.6 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.228 (5.80mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
Datenblatt |
|
EEE-1VA2R2NRCAP ALUM 2.2UF 20% 35V SMD |
19882 | 0.49 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | S | Active | 2.2 µF | ±20% | 35 V | - | 2000 Hrs @ 85°C | -40°C ~ 85°C | Bi-Polar | AEC-Q200 | Automotive | 12 mA @ 120 Hz | 20.4 mA @ 10 kHz | - | - | 0.157 Dia (4.00mm) | 0.213 (5.40mm) | 0.169 L x 0.169 W (4.30mm x 4.30mm) | Surface Mount |
|
Datenblatt |
|
UUD1V470MCL1GSCAP ALUM 47UF 20% 35V SMD |
2346 | 0.48 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UUD | Active | 47 µF | ±20% | 35 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 115 mA @ 120 Hz | 230 mA @ 100 kHz | 440 mOhms | - | 0.248 Dia (6.30mm) | 0.228 (5.80mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
EEE-HA1C470WRCAP ALUM 47UF 20% 16V SMD |
3834 | 0.48 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | HA | Not For New Designs | 47 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -40°C ~ 105°C | Polar | AEC-Q200 | Automotive | 39 mA @ 120 Hz | 66.3 mA @ 10 kHz | - | - | 0.197 Dia (5.00mm) | 0.213 (5.40mm) | 0.209 L x 0.209 W (5.30mm x 5.30mm) | Surface Mount |
|
Datenblatt |
|
UUD1C221MCL1GSCAP ALUM 220UF 20% 16V SMD |
2133 | 0.46 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UUD | Active | 220 µF | ±20% | 16 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 140 mA @ 120 Hz | 280 mA @ 100 kHz | 340 mOhms | - | 0.248 Dia (6.30mm) | 0.303 (7.70mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
UWT1C221MCL1GSCAP ALUM 220UF 20% 16V SMD |
1771 | 0.49 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UWT | Active | 220 µF | ±20% | 16 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 105 mA @ 120 Hz | 157.5 mA @ 10 kHz | - | - | 0.248 Dia (6.30mm) | 0.303 (7.70mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
EMVY350ADA470MF55GCAP ALUM 47UF 20% 35V SMD |
49998 | 0.47 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | Alchip™- MVY | Active | 47 µF | ±20% | 35 V | - | 1000 Hrs @ 105°C | -55°C ~ 105°C | Polar | - | General Purpose | 56 mA @ 120 Hz | 140 mA @ 100 kHz | 1 Ohms | - | 0.248 Dia (6.30mm) | 0.205 (5.20mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
|
Datenblatt |
|
UUD1A101MCL1GSCAP ALUM 100UF 20% 10V SMD |
8757 | 0.48 |
In den WarenkorbJetzt anfragen |
Tape & Reel (TR),Cut Tape (CT),Digi-Reel® | UUD | Active | 100 µF | ±20% | 10 V | - | 2000 Hrs @ 105°C | -55°C ~ 105°C | Polar | AEC-Q200 | Automotive | 115 mA @ 120 Hz | 230 mA @ 100 kHz | 440 mOhms | - | 0.248 Dia (6.30mm) | 0.228 (5.80mm) | 0.260 L x 0.260 W (6.60mm x 6.60mm) | Surface Mount |
