Datenblatt	Mfr. Teil #	Lagerbestand	Preis	Menge	Packaging	Series	RoHS	Speed	Diode Type	Part Status	Mounting Type	Capacitance @ Vr, F	Reverse Recovery Time (trr)	Current - Reverse Leakage @ Vr	Voltage - DC Reverse (Vr) (Max)	Current - Average Rectified (Io)	Operating Temperature - Junction	Voltage - Forward (Vf) (Max) @ If
Datenblatt	EGF1D DIODE GEN PURP 200V 1A SMA onsemi	4962	0.59	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	15pF @ 4V, 1MHz	50 ns	10 µA @ 200 V	200 V	1A	-65°C ~ 175°C	1 V @ 1 A
Datenblatt	EGP10K DIODE GEN PURP 800V 1A DO204AL onsemi	5000	0.49	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Through Hole	-	75 ns	5 µA @ 800 V	800 V	1A	-65°C ~ 150°C	1.7 V @ 1 A
Datenblatt	BAS116HYT116 LOW-LEAKAGE, 80V, 215MA, SOT-23, Rohm Semiconductor	2270	0.39	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Surface Mount	4pF @ 0V, 1MHz	3 µs	5 nA @ 75 V	80 V	215mA (DC)	150°C	1.25 V @ 150 mA
Datenblatt	FE1D DIODE SFR DO-15 200V 1A Diotec Semiconductor	4000	0.07	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Through Hole	-	50 ns	2 µA @ 200 V	200 V	1A	-50°C ~ 175°C	980 mV @ 1 A
Datenblatt	CLLRH-02 BK TIN/LEAD RECTIFIER-GENERAL PURPOSE Central Semiconductor Corp	1448	0.54	- + In den Warenkorb Jetzt anfragen	Box		RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Surface Mount	10pF @ 4V, 1MHz	-	200 nA @ 200 V	200 V	500mA	-65°C ~ 175°C	1.1 V @ 500 mA
Datenblatt	SBRT4U15LP-7 DIODE SBR 15V 4A U-DFN2020-2 Diodes Incorporated	2754	0.59	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Super Barrier	Obsolete	Surface Mount	-	-	100 µA @ 15 V	15 V	4A	-55°C ~ 150°C	470 mV @ 15 A
Datenblatt	BYS12-90-E3/TR3 DIODE SCHOTTKY 90V 1.5A DO214AC Vishay General Semiconductor - Diodes Division	3781	0.49	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	-	-	100 µA @ 90 V	90 V	1.5A	-55°C ~ 150°C	750 mV @ 1 A
Datenblatt	CDBQR70-HF DIODE SCHOTTKY 70V 70MA 0402 Comchip Technology	2084	0.39	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Small Signal =< 200mA (Io), Any Speed	Schottky	Active	Surface Mount	2pF @ 0V, 1MHz	5 ns	100 nA @ 50 V	70 V	70mA	125°C (Max)	1 V @ 15 mA
Datenblatt	RGL34K DIODE FR DO-213AA 800V 0.5A Diotec Semiconductor	2500	0.07	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR)		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	-	500 ns	5 µA @ 800 V	800 V	500mA	-50°C ~ 175°C	1.3 V @ 500 mA
Datenblatt	RB068L150DDTE25 AUTOMOTIVE SCHOTTKY BARRIER DIOD Rohm Semiconductor	1419	0.54	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	-	-	3 µA @ 150 V	150 V	2A	150°C	810 mV @ 2 A
Datenblatt	RF201LAM4STFTR RF201LAM4STF IS THE HIGH RELIABI Rohm Semiconductor	2659	0.59	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	-	30 ns	1 µA @ 400 V	400 V	1.5A	150°C (Max)	1.2 V @ 1.5 A
Datenblatt	SES1DTR UF RECOVERY RECTIFIER 200V SMA SMC Diode Solutions	3621	0.49	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	15pF @ 5V, 1MHz	15 ns	5 µA @ 200 V	200 V	1A	-55°C ~ 150°C	920 mV @ 1 A
	UPS5819E3/TR7 DIODE SMALL-SIGNAL SCHOTTKY Microchip Technology	1979	0.39	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	60pF @ 5V, 1MHz	-	1 mA @ 40 V	40 V	1A	-55°C ~ 150°C	550 mV @ 1 A
Datenblatt	RB058L150DDTE25 AUTOMOTIVE SCHOTTKY BARRIER DIOD Rohm Semiconductor	1144	0.54	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	-	-	3 µA @ 150 V	150 V	3A	150°C	850 mV @ 3 A
Datenblatt	SDURD840TR DIODE GEN PURP 400V 8A DPAK SMC Diode Solutions	1500	0.59	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Standard	Active	Surface Mount	-	45 ns	10 µA @ 400 V	400 V	8A	-55°C ~ 150°C	1.3 V @ 8 A
Datenblatt	PMEG60T20ELPX DIODE SCHOTTKY 60V 2A CFP5 Nexperia USA Inc.	3275	0.49	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	400pF @ 1V, 1MHz	14 ns	1.2 µA @ 60 V	60 V	2A	175°C (Max)	620 mV @ 2 A
Datenblatt	ACGRTS4007-HF DIODE GEN PURP 1000V 1A TS/SOD-1 Comchip Technology	16939	0.39	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Standard Recovery >500ns, > 200mA (Io)	Standard	Active	Surface Mount	6pF @ 4V, 1MHz	-	10 µA @ 1000 V	1000 V	1A	-55°C ~ 150°C	1 V @ 1 A
Datenblatt	RBR1L30ADDTE25 LOW VF TYPE AUTOMOTIVE SCHOTTKY Rohm Semiconductor	1140	0.54	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	-	-	50 µA @ 30 V	30 V	1A	150°C	480 mV @ 1 A
Datenblatt	ACDBC340-HF DIODE SCHOTTKY 40V 3A DO214AB Comchip Technology	1087	0.59	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®	Automotive, AEC-Q101	RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	150pF @ 4V, 1MHz	-	500 µA @ 40 V	40 V	3A	-55°C ~ 125°C	550 mV @ 3 A
Datenblatt	PMEG2015EV,115 DIODE SCHOTTKY 20V 1.5A SOT666 Nexperia USA Inc.	3451	0.49	- + In den Warenkorb Jetzt anfragen	Tape & Reel (TR),Cut Tape (CT),Digi-Reel®		RoHS	Fast Recovery =< 500ns, > 200mA (Io)	Schottky	Active	Surface Mount	25pF @ 5V, 1MHz	-	50 µA @ 15 V	20 V	1.5A (DC)	150°C (Max)	660 mV @ 1.5 A

Total 48193 Records«Prev 1... 132 133 134 135136137 138 139...2410 Next»
